DMPL
Motor + Rope Drive Independent Car
Parking Lift 2200kg
Working Principle
This parking system is designed two spaces
of up and down as one unit. The bottom car
can go in and out directly. When the upper
space needs to park a car, the car in the
bottom should be driven out.
Motor + Rope drive design is independent
lift with faster speed and safe control. It
can be widely used in hotels, enterprises
and public institutions and residential
area. saving land area, full use of space,
property rights;
Characteristics of the System
-
Save land area and take full use of the current space to raise the number of parking cars.
-
The structure is simple, united and easy for operation.
-
It is equipped with multiple safety protection devices and space locked devices.
-
Easy installation and easy operation;
-
Suitable to dismiss and remove to other places;
Adapted places
Family garage, Apartments, yards and lower height of basements areas;
Technical Parameters
| Item | Parameters |
|---|---|
|
Name |
Motor drive 2 post car parking lift |
|
Model |
DMP |
|
Equipment size: |
5100*2476*3940 |
|
Minimum height with car(mm) |
3940 |
|
Car size |
Top-5000*1850*1550
max |
|
Car weight |
2000kg |
|
Parking cars |
2 |
|
Lift time |
24S |
|
Lift speed |
4.5m |
|
Motor power |
2.2kw |
|
Fall speed |
4.5m |
|
Mode of drive |
Motor + Steel rope |
|
Mode of operation |
Button / Manual |
|
Electrics |
220v, single phase 50HZ; 380V, 3 phases, 50HZ; |
|
Parking way |
Top-Forward |
|
Model |
D2P27 |
|
Parking Lift Dimensions |
4810*2666*2084mm |
|
Out package dimensions |
4200*500*700 |
|
Max Car Weight |
2700kg |
|
Inner columns width |
2350mm |
|
Central column width |
2454mm |
|
Width between two outside columns |
2555mm |
|
Distance between drive boards |
969mm |
|
Total height |
2084mm |
|
Max Lifting Height |
1800mm |
|
Lifting Time |
50S |
|
Fall Time |
60S |
|
Motor |
2.2kw |
|
Mode of operation |
Manual Button |
|
Mode of control |
Hydraulic + Chain |
|
Mode of unlocking |
Manual |
|
Electricity |
50HZ, 220V, 1P/380V, 3P; |
|
Noise |
75dB, max |
|
Packing size each unit |
4200*630*630mm |
